Unleashing Design Freedom on Walls with Versatile, Eco-Friendly Solutions

Recognizing each project’s challenges, we offer an extensive range of wall systems. From meticulously crafted custom solutions including: mitered corners, brake formed, roll-formed, plate, and perforated panels that let sunlight filter through. Our wall solutions ensure a tailored metal envelope solution for every vision.

Crafting Excellence One Panel at a Time

Design freedom is not just for the roof. We extend freedom of architectural expression to the wall/facade as well. Every project has unique challenges, and we produce solutions for the building enclosure and interior finishes.

Accure® Single Skin Wall Panels

Accure is a plate/cassette-style flat panel with a reveal joint. This system gives a flat metal wall aesthetic with a number or material and finish options including painted steel, painted and anodized aluminum, weathering steel, copper, zinc, and stainless steel. The system can be made in varying depths, producing tapered and non-planer faces that play with light and shadow.

Material Thickness

  • Range: .024″ – .080″

Standard Dimensions

  • Height: 12″ – 48″
  • Width: 18″ – 120″
  • Custom dimensions available

Legend

Coping Cap
X
Vertical Joints
X
Horizontal Joints
X
Soffit at Fascia
X
Outside Corner
X
Inside Corner
X
Soffit at Wall
X
Wall Base
X
Door Head
X
Door Jamb
X
Window Head
X
Window Jamb
X
Window Sill
X
Louver Head
X
Louver Jamb
X
Louver Sill
X

Aspect® ACM and Plate Wall Panels

Aspect Wall Systems offers an innovative solution in architectural metal plate and ACM (Aluminum Composite Material) wall systems. Aspect extrusions are a continuous male/female system which is designed to enable much faster and smoother installation than a typical clip system. By making alignment from one panel to the next much faster and more repeatable, contractors spend less time on installation.

Material Thickness

  • Plate: 3mm / .125″
  • ACM: 4mm / .1574″

Standard Dimensions

  • Range from 12″ x 12″ – 60″ x 196″
  • Custom dimensions available

Legend

Horizontal Joint Detail
X
Vertical Joint Detail
X
Outside Corner Detail
X
Inside Corner Detail
X
Window Head Detail
X
Door Head Detail
X
Window Jamb Detail
X
Door Jamb Detail
X
Window Sill Detail
X
Wall Base Detail
X
Fascia-Soffit Detail
X
Wall-Soffit Detail
X
Parapet Detail
X

INVISIO™: Invisible Attachment

This system offers architects and designers the possibility of using exceptionally large panel sizes (240″x72″) with near-invisible seams. The joint depths are only as thick as the material instead of the typical 1″ return. This reduced depth in the joint gives a much smoother appearance to the facade and reduces the joint visibility. The patented INVISIO keyhole attachment allows fixation throughout the entire back side of the panel while being invisible from the face and not relying on sealant or adhesive. The linear expansion of panels is compensated through the sliding fastenings to substructure rails. All edges of INVISIO panels are folded, keeping the core covered with the panel’s finish.

Material Thickness

  • Range: .125″ – .25″

Standard Dimensions

  • 12″ x 12″ – 60″ x 196″
  • Custom dimensions available

Perforated Graphic Imaging (PGI)®

BEMO brings an innovative approach to architectural design with its Perforated Graphic Imaging (PGI) technology. This enables architects to bring their visions to life by incorporating perforated images into metal panels. Whether it is a subtle pattern or a high resolution, artistic statement, the precision of perforation ensures that every detail is captured with remarkable clarity. The scale of these images is limited only by the size of the building itself, allowing for grand and impactful designs. These panels can be used for exterior facades and interior finishes. This technology can also be used to create brand identity and wayfinding which provides a unique aesthetic appeal.

Light

Material Thickness

  • Range: .040″ – .080″



Standard Dimensions

  • 12″ x 12″ – 96″ x 24″
  • Custom dimensions available
Heavy

Material Thickness

  • Range: .080″ – .1875″



Standard Dimensions

  • 24″ x 24″ – 60″ x 120″
  • Custom dimensions available

Custom Wall Panel Systems

BEMO custom wall solutions can be used to achieve any architectural aesthetics while still meeting demanding performance criteria. BEMO specializes in design and engineering of unique attachment systems for complex surfaces and requirements.
